JBL Synthesis SDA-8300 Power Amplifier

Name: JBL Synthesis SDA-8300 Power Amplifier
Brand: JBL
SKU: 33560
Availability: InStock

6999,00 €

The SDA-8300 is a versatile 8-channel Class D power amplifier designed to deliver maximum power while taking up minimal rack space. Each channel is rated to deliver 300W into 8 ohms and adjacent channel pairs can be bridged to deliver 600W into 8 ohms. This flexible channel configuration makes this an ideal amplifier to power LCR, surround, and height channel loudspeakers as well as in-wall subwoofers in JBL Synthesis immersive audio systems.

Add to wishlist

Description

Overview

The SDA-8300 and SDA-4600 represent the next-generation of JBL Synthesis power amplifiers and offer significantly improved performance along with flexible networking capabilities in a JBL Synthesis custom-installation home theater system. Adding to their appeal, the new amplifiers sound better, offer exceptional energy efficiency and have space-saving form factors that allow greater placement and installation flexibility.

The new amplifiers are designed to work hand in hand with other JBL Synthesis electronics. Both models offer networked digital audio and control connectivity to JBL Synthesis surround sound preamplifiers, equalizers and other components via the amplifiers’ primary and secondary Ethernet transport ports. The SDA-8300 and SDA-4600 connect to a JBL Synthesis SDEC-4500 equalizer via an Ethernet cable.

In addition the amplifiers are just as happy to work as traditional analogue amplifiers having 8 analogue balance or single ended input on the SDA8300 and 4 on the SDA4600.

SPECIFICATIONS

Inputs:	Balanced 3-pin block connectors, one per channel
Rated Output Power Into 8 Ohms:	300
Rated Output Power Into 4 Ohms:	300
Rated Output Power Into 2 Ohms:	150
Bridged Output Power Into 8 Ohms:	600
Damping Factor:	1000
7-Volt Capable:	Voltage Gain (at Maximum Level Setting) 34 dB
Analog Input Signal to Noise Ratio:	104 dB
BLU Link Signal-to-Noise Ratio:	108 dB
Speaker Specifications
Frequency Response:	+/-0.25db
Signal-to-Noise Ratio:	>108db
Total Harmonic Distortion (THD):	<0.35%
Power Requirements (+/-10%):	100VAC – 240VAC 50/60hz
Dimensions
Height:	3.5″ (8.75 cm)
Width:	19″ (47.5 cm)
Depth:	14.25″ (35.63 cm)
Weight:	23.5 lbs (10.66 kg)

About JBL

The History JBL is an American company that manufactures audio equipment, including loudspeakers and headphones. JBL Consumer serves the consumer home market. JBL Professional serves the studio, installed sound, tour sound, portable sound, cars, production, disc jockey, cinema markets, etc. JBL is owned by Harman International Industries a subsidiary of Samsung Electronics. JBL was founded by James Bullough Lansing (1902–1949), an American audio engineer and loudspeaker designer best known for establishing two audio companies that bear his name, Altec Lansing and JBL, the latter taken from his initials.
